For model ST250 32091, Loewe-(Opta); Deutschland

Country:  Germany
Manufacturer / Brand:  Loewe-(Opta); Deutschland
alternative name

Löwe Radio
Year: 1970–1973 Category: Broadcast Receiver - or past WW2 Tuner
Semiconductors (the count is only for transistors) 40: BF244 BF224 BF195 BF194 BF173 BC140 BC147 BC172 BC173 BC182 BC183 BC184 BC213 BC252 BC264 TIP29 TIP30 2N5036 AD149 BB104 AA112 AA118 AA119 1N4148 BZ102/1V4 ZD15 ZF27 ZF7,5 B40C3200
Main principle Superheterodyne (common); ZF/IF 460/10700 kHz
Tuned circuits 7 AM circuit(s)     12 FM circuit(s)
Wave bands Broadcast, (BC) Long Wave (LW), 2 x SW and FM or UHF.
Details
Power type and voltage Alternating Current supply (AC) / 110; 120; 130; 220; 230; 240 Volt
Loudspeaker - This model requires external speaker(s).
Power out 50 W (undistorted)
from Radiomuseum.org Model: ST250 32091 - Loewe-Opta; Deutschland
Material Wooden case
Shape Book-shelf unit.
Dimensions (WHD) 620 x 130 x 250 mm / 24.4 x 5.1 x 9.8 inch
Notes

HiFi-Stereo-Steuergerät. NF-Verstärker mit 2 Endstufen je 25 W (Sinus).
Gehäuse: Nussbaum, natur mattiert oder Schleiflack, weiss.

Modell wurde unter Bezeichnung Senator Hifi-Stereo-Steuergerät VT314 von der Quelle GmbH (Fürth) vertrieben.

Halbleiter teils mehrfach vorhanden

UKW: 87,5-104 MHz
K1: 7,0-15.6 MHz
K2: 5,94-6,25 MHz
M: 513-1620 kHz
L: 147-350 kHz

Net weight (2.2 lb = 1 kg) 7.5 kg / 16 lb 8.3 oz (16.52 lb)
External source of data Erb
Source of data Handbuch VDRG 1970/1971
