Weltspiegel 52T

Weltspiegel 52T; Lorenz; Berlin, (ID = 410670) Television

Weltspiegel 52T; Lorenz; Berlin, (ID = 410671) Television

Weltspiegel 52T; Lorenz; Berlin, (ID = 2404165) Television

Weltspiegel 52T; Lorenz; Berlin, (ID = 2404166) Television

Weltspiegel 52T; Lorenz; Berlin, (ID = 2404167) Television

Weltspiegel 52T; Lorenz; Berlin, (ID = 2404169) Television

Weltspiegel 52T; Lorenz; Berlin, (ID = 2404170) Television

Weltspiegel 52T; Lorenz; Berlin, (ID = 2404171) Television

Weltspiegel 52T; Lorenz; Berlin, (ID = 2404172) Television
Weltspiegel 52T; Lorenz; Berlin, (ID = 235371) Television Weltspiegel 52T; Lorenz; Berlin, (ID = 410391) Television
Weltspiegel 52T; Lorenz; Berlin, (ID = 410392) Television Weltspiegel 52T; Lorenz; Berlin, (ID = 410393) Television
Weltspiegel 52T; Lorenz; Berlin, (ID = 410394) Television Weltspiegel 52T; Lorenz; Berlin, (ID = 410395) Television
Weltspiegel 52T; Lorenz; Berlin, (ID = 410396) Television Weltspiegel 52T; Lorenz; Berlin, (ID = 410397) Television
Weltspiegel 52T; Lorenz; Berlin, (ID = 410398) Television Weltspiegel 52T; Lorenz; Berlin, (ID = 410399) Television
Use red slider bar for more.
Weltspiegel 52T; Lorenz; Berlin, (ID = 235371) Television
Lorenz; Berlin,: Weltspiegel 52T [Television] ID = 235371 615x482
Select picture or schematic to display from thumbnails on the right and click for download.
For model Weltspiegel 52T, Lorenz; Berlin, Zuffenhausen u.a.

Country:  Germany
Manufacturer / Brand:  Lorenz; Berlin, Zuffenhausen u.a.
Brand

SEL
Year: 1951/1952 Category: Television Receiver (TV) or Monitor
Valves / Tubes 22: EF80 ECC81 EF80 EF80 EF80 EF80 EL41 EF80 EF80 EAA91 EAF42 EL41 PCL81 ECC82 EEL71 ECC81 PL81 PY83 EY51 AZ12 AZ12 Bm35R-1 or Bm35R-2
Conflicting model year with tubedata.
The model date contradicts tube dates. [ PY83 (1952)]
Wave bands Wave Bands given in the notes.
Details
Power type and voltage Alternating Current supply (AC) / 110-240 Volt
Loudspeaker Permanent Magnet Dynamic (PDyn) Loudspeaker (moving coil)
Power out
from Radiomuseum.org Model: Weltspiegel 52T - Lorenz; Berlin, Zuffenhausen u
Material Wooden case
Shape Tablemodel, with any shape - general.
Dimensions (WHD) 620 x 470 x 480 mm / 24.4 x 18.5 x 18.9 inch
Notes VHF Band I und III. Bildröhre Bm35-R1 oder Bm35-R2.
Net weight (2.2 lb = 1 kg) 39.7 kg / 87 lb 7.1 oz (87.445 lb)
Mentioned in Funk-Technik (FT) (FT51, FT53)

Model page created by Folkert Rothe. See "Data change" for further contributors.
