For model Ballade, Lumophon, Bruckner & Stark, Nürnberg

Country:  Germany
Manufacturer / Brand:  Lumophon, Bruckner & Stark, Nürnberg
Brand

Lumeta
Year: 1967–1969 Category: Broadcast Receiver - or past WW2 Tuner
Valves / Tubes 6: ECC85 ECH81 EAF801 ECC83 EM87 ELL80
Main principle Superheterodyne (common)
Tuned circuits 6 AM circuit(s)     10 FM circuit(s)
Wave bands Broadcast, Long Wave, Short Wave plus FM or UHF.
Details Changer (Record changer)
Power type and voltage Alternating Current supply (AC) / 110; 130; 220; 240 Volt
Loudspeaker 2 Loudspeakers
Power out
from Radiomuseum.org Model: Ballade - Lumophon, Bruckner & Stark,
Material Wooden case
Shape Console with Push Buttons.
Dimensions (WHD) 1330 x 760 x 360 mm / 52.4 x 29.9 x 14.2 inch
Notes Rundfunk-Chassis = Grundig RF160; Stereo-Decoder 6 nachrüstbar; Stereo-NF-Verstärker mit 2 Endstufen je 3 W;
Phono-Chassis = Philips AG1035 mit Kristallsystem AG3306.
Net weight (2.2 lb = 1 kg) 45 kg / 99 lb 1.9 oz (99.119 lb)
External source of data erb
Source of data Handbuch VDRG 1968/1969
