Country:  Finland
Manufacturer / Brand:  Luxor, Helsinki - see also Sweden
alternative name

Iskumetalli Oy
Year: 1961 ? Category: Television Receiver (TV) or Monitor
Valves / Tubes 21: PCC88 PCF80 EF80 EF80 EF80 EF94 EF94 EBF89 PL82 PCF80 PCF80 ECH81 ECC81 PCF80 PL36 ECC81 PL84 DY86 PY88 ECH81 AW59-90
Main principle Superheterodyne (common)
Wave bands VHF incl. FM and/or UHF (see notes for details)
Details
Power type and voltage Alternating Current supply (AC) / 220 Volt
Loudspeaker Permanent Magnet Dynamic (PDyn) Loudspeaker (moving coil)
Power out 2.5 W (unknown quality)
from Radiomuseum.org Model: 21220 - Luxor, Helsinki - see also
Material Wooden case
Notes VHF only. 10 CCIR-channels and OIR -channel (Tallinn).
Literature/Schematics (1) -- Schematic

Model page created by Jouko Laukkanen. See "Data change" for further contributors.
