• Country
• Finland

• Manufacturer / Brand
• Luxor, Helsinki - see also Sweden

• Year
• 1961 ?

• Category
• Television Receiver (TV) or Monitor

• Radiomuseum.org ID
• 171160

• • alternative name: Iskumetalli Oy

Click on the schematic thumbnail to request the schematic as a free document.

• Number of Tubes
• 21

• Valves / Tubes
• PCC88 PCF80 EF80 EF80 EF184 ECH81 EF94 EF94 EBF89 PL82 PCF80 PCF80 ECH81 ECC81 PCF80 PL36 ECC81 PL84 DY86 PY88 AW59-90

• Main principle
• Superheterodyne (common)

• Wave bands
• VHF incl. FM and/or UHF (see notes for details)

• Loudspeaker
• Permanent Magnet Dynamic (PDyn) Loudspeaker (moving coil)

• Power out
• 2.5 W (unknown quality)

• Material
• Wooden case

• from Radiomuseum.org
• Model: 58100 - Luxor, Helsinki - see also

• Notes
• VHF only, UHF optional. 10 CCIR-channels and 1 OIR-channel (Tallinn).

• Literature/Schematics (1)
• -- Schematic

• Author
• Model page created by Jouko Laukkanen. See "Data change" for further contributors.
