• Country
• Italy

• Manufacturer / Brand
• Lyraphon Radio; Torino

• Year
• 1932/1933 ?

• Category
• Broadcast Receiver - or past WW2 Tuner

• Radiomuseum.org ID
• 222419

• Number of Tubes
• 3

• Valves / Tubes
• 57 42 80

• Main principle
• TRF (Tuned-Radio-Frequency but use of regeneration unknown); Reflex

• Wave bands
• Broadcast only (MW).

• Power type and voltage
• Alternating Current supply (AC) / 110; 125; 160; 220 Volt

• Loudspeaker
• Electro Magnetic Dynamic LS (moving-coil with field excitation coil) / Ø 16 cm = 6.3 inch

• Power out
• 1.5 W (unknown quality)

• Material
• Wooden case

• from Radiomuseum.org
• Model: Lyrette 3 - Lyraphon Radio; Torino

• Shape
• Tablemodel, high profile (upright - NOT Cathedral nor decorative).

• Dimensions (WHD)
• 250 x 400 x 160 mm / 9.8 x 15.7 x 6.3 inch

• Net weight (2.2 lb = 1 kg)
• 6 kg / 13 lb 3.5 oz (13.216 lb)

• Author
• Model page created by Antonio Siciliano. See "Data change" for further contributors.
