For model SV56, Magnadyne Radio; Torino
Country:  Italy
Manufacturer / Brand:  Magnadyne Radio; Torino
Year: 1938/1939 Category: Broadcast Receiver - or past WW2 Tuner
Valves / Tubes 5: 6A8 6K7 6Q7 6V6 80
Main principle Superheterodyne (common); ZF/IF 471 kHz
Wave bands Broadcast, Long Wave and 2 x Short Wave.
Power type and voltage Alternating Current supply (AC) / 110; 125; 140; 155; 175; 230 Volt
Loudspeaker Electro Magnetic Dynamic LS (moving-coil with field excitation coil)
Power out
from Model: SV56 - Magnadyne Radio; Torino
Material Wooden case
Shape Tablemodel, low profile (big size).
Dimensions (WHD) 580 x 300 x 320 mm / 22.8 x 11.8 x 12.6 inch
Notes Controllo di selettività variabile. Dispositivo Multitonal. SV56 è un soprammobile: per il radiofonografo console con chassis SV56, si veda il mod. SV156.
Net weight (2.2 lb = 1 kg) 13 kg / 28 lb 10.1 oz (28.634 lb)
Price in first year of sale 1'475.00 ITL
Source of data Guida Pratica Antique Radio (1) 1999
Literature/Schematics (1) Il Radio Libro (E.D. Ravalico) Edizioni Hoepli
Literature/Schematics (2) Il Radio Libro, (Ravalico) 6a edizione 1942

Model page created by Alessandro De Poi. See "Data change" for further contributors.
