For model Calipso II (2) 12, Marelli (Radiomarelli); Sesto San Giovanni (MI)

Country:  Italy
Manufacturer / Brand:  Marelli (Radiomarelli); Sesto San Giovanni (MI)
Year: 1934 Category: Broadcast Receiver - or past WW2 Tuner
Valves / Tubes 5: 6A7 78 75 41 80
Main principle Superheterodyne (common); ZF/IF 125 kHz
Wave bands Broadcast (MW) and Long Wave.
Details Record Player (not changer); Visual Tuning Indicator pre Eye
Power type and voltage Alternating Current supply (AC) / 110, 160, 220 Volt
Loudspeaker Electro Magnetic Dynamic LS (moving-coil with field excitation coil)
Power out
from Radiomuseum.org Model: Calipso II 12 - Marelli Radiomarelli; Sesto
Material Wooden case
Shape Console, Highboy (legs > 50 %).
Dimensions (WHD) 665 x 995 x 400 mm / 26.2 x 39.2 x 15.7 inch
Notes

Variante (piccole variazioni del circuito) del Radiomarelli Damayante.

Strumento indicatore di sintonia.

Presenti 2 schemi leggermente diversi, con e senza l'indicatore di sintonia.

Lo "Schemario degli Apparecchi Radio" D.E. Ravalico Seconda edizione - Hoepli - 1945 indica il Calipso II come radiofonografo senza indicatore di sintonia ed il Damayante (senza giradischi), con lo strumento indicatore di sintonia.

Price in first year of sale 2'250.00 ITL
Source of data Guida Pratica Antique Radio (1) 1999
Mentioned in La moderna Supereterodina, Ravalico, 1938 (pag. 371)
Literature/Schematics (1) -- Schematic (Il Manuale del Radiomeccanico G.B. Angeletti – Radio Industria – 1945)
Literature/Schematics (2) Schemario di apparecchi radio a valvole (II edizione, D.E. Ravalico - Hoepli - 1945)

Model page created by Alessandro De Poi. See "Data change" for further contributors.
