Fido 9U65F

Fido 9U65F; Marelli Radiomarelli (ID = 96455) Radio

Fido 9U65F; Marelli Radiomarelli (ID = 96766) Radio

Fido 9U65F; Marelli Radiomarelli (ID = 215790) Radio

Fido 9U65F; Marelli Radiomarelli (ID = 215791) Radio

Fido 9U65F; Marelli Radiomarelli (ID = 215792) Radio
Fido 9U65F; Marelli Radiomarelli (ID = 523202) Radio Fido 9U65F; Marelli Radiomarelli (ID = 578912) Radio
Fido 9U65F; Marelli Radiomarelli (ID = 695026) Radio Fido 9U65F; Marelli Radiomarelli (ID = 2128340) Radio
Fido 9U65F; Marelli Radiomarelli (ID = 2128341) Radio Fido 9U65F; Marelli Radiomarelli (ID = 2128342) Radio
Use red slider bar for more.
Fido 9U65F; Marelli Radiomarelli (ID = 523202) Radio
Marelli Radiomarelli: Fido 9U65F [Radio] ID = 523202 381x215
Select picture or schematic to display from thumbnails on the right and click for download.
For model Fido 9U65F, Marelli (Radiomarelli); Sesto San Giovanni (MI):
This is a Radiomarelli model 9U65F

Country:  Italy
Manufacturer / Brand:  Marelli (Radiomarelli); Sesto San Giovanni (MI)
Year: 1947 Category: Broadcast Receiver - or past WW2 Tuner
Valves / Tubes 5: 12EA7GT 12NK7GT 12Q7GT 50L6GT 35Z5GT
Main principle Super-Heterodyne (Super in general); ZF/IF 455 kHz
Wave bands Broadcast plus 2 Short Wave bands.
Details
Power type and voltage AC/DC-set / 125, 135, 160, 175 Volt
Loudspeaker Permanent Magnet Dynamic (PDyn) Loudspeaker (moving coil) / Ø 10 cm = 3.9 inch
Power out 1.2 W (unknown quality)
from Radiomuseum.org Model: Fido 9U65F - Marelli Radiomarelli; Sesto
Material Bakelite case
Shape Tablemodel, Mantel/Midget/Compact up to 14" width, but not a Portable (See power data. Sometimes with handle but for mains only).
Dimensions (WHD) 250 x 130 x 90 mm / 9.8 x 5.1 x 3.5 inch
Net weight (2.2 lb = 1 kg) 2 kg / 4 lb 6.5 oz (4.405 lb)
Collectors' prices
External source of data Alessandro De Poi - http://www.depoi.net
Source of data Collezione di Schemi, Scuola Radio Elettra 1953
Mentioned in Schemi di apparecchi radio ( Ravalico 1953 ) (pag. 151; Guida Pratica Antique Radio II)
Literature/Schematics (1) Riparazioni - Scuola Radio Elettra (pag. M30-M31)

Model page created by Ernst Erb. See "Data change" for further contributors.
