Fido RD135

Fido RD135; Marelli Radiomarelli (ID = 573482) Radio

Fido RD135; Marelli Radiomarelli (ID = 770901) Radio
Fido RD135; Marelli Radiomarelli (ID = 276771) Radio Fido RD135; Marelli Radiomarelli (ID = 1654843) Radio
Fido RD135; Marelli Radiomarelli (ID = 1177797) Radio Fido RD135; Marelli Radiomarelli (ID = 1177798) Radio
Fido RD135; Marelli Radiomarelli (ID = 1615626) Radio Fido RD135; Marelli Radiomarelli (ID = 1615627) Radio
Fido RD135; Marelli Radiomarelli (ID = 1615628) Radio Fido RD135; Marelli Radiomarelli (ID = 1654844) Radio
Use red slider bar for more.
Fido RD135; Marelli Radiomarelli (ID = 276771) Radio
Marelli Radiomarelli: Fido RD135 [Radio] ID = 276771 640x480
Select picture or schematic to display from thumbnails on the right and click for download.
For model Fido RD135, Marelli (Radiomarelli); Sesto San Giovanni (MI)

Country:  Italy
Manufacturer / Brand:  Marelli (Radiomarelli); Sesto San Giovanni (MI)
Year: 1953 Category: Broadcast Receiver - or past WW2 Tuner
Valves / Tubes 5: 12BE6 12BA6 12AT6 50B5 35W4
Main principle Super-Heterodyne (Super in general); ZF/IF 455 kHz
Wave bands Broadcast only (MW).
Details
Power type and voltage AC/DC-set / 125-175 Volt
Loudspeaker Permanent or electro-dynamic (moving coil), system not known yet. / Ø 10 cm = 3.9 inch
Power out 2.2 W (unknown quality)
from Radiomuseum.org Model: Fido RD135 - Marelli Radiomarelli; Sesto
Material Moulded (Bakelite or Plastics)
Shape Tablemodel, Mantel/Midget/Compact up to 14" width, but not a Portable (See power data. Sometimes with handle but for mains only).
Dimensions (WHD) 240 x 140 x 110 mm / 9.4 x 5.5 x 4.3 inch
Price in first year of sale 23'300.00 ITL
Collectors' prices
Source of data Guida Pratica Antique Radio II (2000)
Mentioned in -- Original prospect or advert (L'antenna, n.12, dicembre 1953)
Literature/Schematics (1) -- Schematic

Model page created by Alessandro De Poi. See "Data change" for further contributors.
