RD162

RD162; Marelli Radiomarelli (ID = 771048) Radio

RD162; Marelli Radiomarelli (ID = 950830) Radio
Use red slider bar for more.
RD162; Marelli Radiomarelli (ID = 771048) Radio
Select picture or schematic to display from thumbnails on the right and click for download.

Country:  Italy
Manufacturer / Brand:  Marelli (Radiomarelli); Sesto San Giovanni (MI)
Year: 1955/1956 Category: Broadcast Receiver - or past WW2 Tuner
Valves / Tubes 8: 6BE6 6BA6 6AT6 12AU7 6E5 6V6 6V6 5Y3
Main principle Super-Heterodyne (Super in general); ZF/IF 455 kHz
Wave bands Wave Bands given in the notes.
Details Record Player (not changer)
Power type and voltage Alternating Current supply (AC) / 110; 125; 140; 160; 220 Volt
Loudspeaker Permanent Magnet Dynamic (PDyn) Loudspeaker (moving coil)
Power out 7 W (unknown quality)
from Radiomuseum.org Model: RD162 - Marelli Radiomarelli; Sesto
Material Wooden case
Shape Tablemodel, low profile (big size).
Dimensions (WHD) 680 x 370 x 370 mm / 26.8 x 14.6 x 14.6 inch
Notes Gamme d'onda: medie, corte, tropicali.
Wave bands: BC, SW, tropical.
Source of data Guida Pratica Antique Radio (1) 1999
Literature/Schematics (1) -- Schematic

Model page created by Alessandro De Poi. See "Data change" for further contributors.
