RD178 MF

RD178 MF; Marelli Radiomarelli (ID = 328595) Radio

RD178 MF; Marelli Radiomarelli (ID = 328596) Radio

RD178 MF; Marelli Radiomarelli (ID = 771016) Radio

RD178 MF; Marelli Radiomarelli (ID = 771020) Radio

RD178 MF; Marelli Radiomarelli (ID = 827538) Radio

RD178 MF; Marelli Radiomarelli (ID = 827539) Radio
RD178 MF; Marelli Radiomarelli (ID = 989489) Radio RD178 MF; Marelli Radiomarelli (ID = 1053486) Radio
Use red slider bar for more.
RD178 MF; Marelli Radiomarelli (ID = 989489) Radio
Marelli Radiomarelli: RD178 MF [Radio] ID = 989489 474x286
Select picture or schematic to display from thumbnails on the right and click for download.
For model RD178 MF, Marelli (Radiomarelli); Sesto San Giovanni (MI):
La radio appartiene a un mio amico dal 1960.

Country:  Italy
Manufacturer / Brand:  Marelli (Radiomarelli); Sesto San Giovanni (MI)
Year: 1956/1957 Category: Broadcast Receiver - or past WW2 Tuner
Valves / Tubes 7: 12AT7 6AJ8 6BA6 6T8 6E5-M 6BQ5 5Y3
Main principle Super-Heterodyne (Super in general); ZF/IF 455/10700 kHz
Wave bands Broadcast, 2 Short Wave plus FM or UHF.
Details Record Player (not changer)
Power type and voltage Alternating Current supply (AC) / 110; 125; 140; 160; 220 Volt
Loudspeaker 2 Loudspeakers
Power out
from Radiomuseum.org Model: RD178 MF - Marelli Radiomarelli; Sesto
Material Wooden case
Shape Tablemodel with Push Buttons.
Dimensions (WHD) 530 x 330 x 340 mm / 20.9 x 13 x 13.4 inch
Source of data Guida Pratica Antique Radio (1) 1999
Literature/Schematics (1) -- Schematic

Model page created by Alessandro De Poi. See "Data change" for further contributors.



All listed radios etc. from Marelli (Radiomarelli); Sesto San Giovanni (MI)
Here you find 435 models, 325 with images and 247 with schematics for wireless sets etc. In French: TSF for Télégraphie sans fil.
