RD200; Marelli Radiomarelli (ID = 276240) Radio
Marelli Radiomarelli: RD200 [Radio] ID = 276240 323x250
Select picture or schematic to display from thumbnails on the right and click for download.
For model RD200, Marelli (Radiomarelli); Sesto San Giovanni (MI):
Foto per cortesia del venditore ebay: orsomaria62

Country:  Italy
Manufacturer / Brand:  Marelli (Radiomarelli); Sesto San Giovanni (MI)
Year: 1959/1960 Category: Broadcast Receiver - or past WW2 Tuner
Valves / Tubes 5: 12BE6 12BA6 12AT6 50B5 35W4
Main principle Super-Heterodyne (Super in general); ZF/IF 455 kHz
Wave bands Broadcast only (MW).
Details
Power type and voltage Alternating Current supply (AC) / 110; 125; 145; 160; 220 Volt
Loudspeaker Permanent Magnet Dynamic (PDyn) Loudspeaker (moving coil) - elliptical
Power out 1.5 W (unknown quality)
from Radiomuseum.org Model: RD200 - Marelli Radiomarelli; Sesto
Material Bakelite case
Shape Tablemodel, Mantel/Midget/Compact up to 14" width, but not a Portable (See power data. Sometimes with handle but for mains only).
Dimensions (WHD) 240 x 150 x 110 mm / 9.4 x 5.9 x 4.3 inch
Notes Serie ANIE MA. Telaio a circuito stampato.
Net weight (2.2 lb = 1 kg) 2.1 kg / 4 lb 10 oz (4.626 lb)
Price in first year of sale 18'800.00 ITL
Collectors' prices
Source of data Guida Pratica Antique Radio II (2000)
Mentioned in -- Original prospect or advert
Literature/Schematics (1) -- Schematic

Model page created by Alessandro De Poi. See "Data change" for further contributors.
