RD213

RD213; Marelli Radiomarelli (ID = 517144) Radio

RD213; Marelli Radiomarelli (ID = 674122) Radio
RD213; Marelli Radiomarelli (ID = 2160106) Radio RD213; Marelli Radiomarelli (ID = 2160107) Radio
RD213; Marelli Radiomarelli (ID = 2160108) Radio RD213; Marelli Radiomarelli (ID = 2160109) Radio
RD213; Marelli Radiomarelli (ID = 2160110) Radio RD213; Marelli Radiomarelli (ID = 517659) Radio
RD213; Marelli Radiomarelli (ID = 517660) Radio RD213; Marelli Radiomarelli (ID = 517661) Radio
RD213; Marelli Radiomarelli (ID = 517662) Radio RD213; Marelli Radiomarelli (ID = 517663) Radio
Use red slider bar for more.
RD213; Marelli Radiomarelli (ID = 2160106) Radio
Marelli Radiomarelli: RD213 [Radio] ID = 2160106 1129x1200
Select picture or schematic to display from thumbnails on the right and click for download.
For model RD213, Marelli (Radiomarelli); Sesto San Giovanni (MI)

Country:  Italy
Manufacturer / Brand:  Marelli (Radiomarelli); Sesto San Giovanni (MI)
Year: 1958 Category: Broadcast Receiver - or past WW2 Tuner
Valves / Tubes 6: 12AT7 12AJ8 12BA6 19T8 35QL6 35X4
Main principle Super-Heterodyne (Super in general)
Wave bands Broadcast, Short Wave plus FM or UHF.
Details Record Player (not changer)
Power type and voltage Alternating Current supply (AC) / 110; 125; 140; 160; 220 Volt
Loudspeaker Permanent Magnet Dynamic (PDyn) Loudspeaker (moving coil) - elliptical
Power out 2.5 W (unknown quality)
from Radiomuseum.org Model: RD213 - Marelli Radiomarelli; Sesto
Material Wooden case
Shape Tablemodel with Push Buttons.
Dimensions (WHD) 490 x 310 x 300 mm / 19.3 x 12.2 x 11.8 inch
Net weight (2.2 lb = 1 kg) 10 kg / 22 lb 0.4 oz (22.026 lb)
Price in first year of sale 63'000.00 ITL
Collectors' prices
Source of data Guida Pratica Antique Radio II (2000)
Mentioned in -- Original prospect or advert

Model page created by Alessandro De Poi. See "Data change" for further contributors.



All listed radios etc. from Marelli (Radiomarelli); Sesto San Giovanni (MI)
Here you find 435 models, 325 with images and 247 with schematics for wireless sets etc. In French: TSF for Télégraphie sans fil.
