Marelli Radiomarelli: RV 680B T-034-00 [Television] ID = 1253845 640x480
Select picture or schematic to display from thumbnails on the right and click for download.
For model RV 680B T-034-00, Marelli (Radiomarelli); Sesto San Giovanni (MI)

Country:  Italy
Manufacturer / Brand:  Marelli (Radiomarelli); Sesto San Giovanni (MI)
Year: 1980 ?? Category: Television Receiver (TV) or Monitor
Valves / Tubes 1: 17BM120
Semiconductors (the count is only for transistors) Semiconductors present.
Main principle Super-Heterodyne (Super in general)
Wave bands VHF incl. FM and/or UHF (see notes for details)
Details
Power type and voltage Alternating Current supply (AC) / 220 Volt
Loudspeaker Permanent Magnet Dynamic (PDyn) Loudspeaker (moving coil)
Power out
from Radiomuseum.org Model: RV 680B T-034-00 - Marelli Radiomarelli; Sesto
Material Modern plastics (no Bakelite or Catalin)
Shape Tablemodel with Push Buttons.
Dimensions (WHD) 500 x 400 x 300 mm / 19.7 x 15.7 x 11.8 inch
Notes Marelli RV680B: black and whitze television set with four pushbutton station presets.
Televisore Bianco e Nero da 17 Pollici 4 canali memorizzabili realizzato in plastica bianca

Model page created by Raffaele Pedrini. See "Data change" for further contributors.
