Sconosciuto/Unknown (Autoradio MW/LW)

Sconosciuto/Unknown ; Marelli Radiomarelli (ID = 2176162) Car Radio Sconosciuto/Unknown ; Marelli Radiomarelli (ID = 2176163) Car Radio
Sconosciuto/Unknown ; Marelli Radiomarelli (ID = 2176164) Car Radio Sconosciuto/Unknown ; Marelli Radiomarelli (ID = 2176165) Car Radio
Sconosciuto/Unknown ; Marelli Radiomarelli (ID = 2176166) Car Radio Sconosciuto/Unknown ; Marelli Radiomarelli (ID = 2176167) Car Radio
Use red slider bar for more.
Sconosciuto/Unknown ; Marelli Radiomarelli (ID = 2176162) Car Radio
Marelli Radiomarelli: Sconosciuto/Unknown [Car Radio] ID = 2176162 1400x1050
Select picture or schematic to display from thumbnails on the right and click for download.
For model Sconosciuto/Unknown (Autoradio MW/LW), Marelli (Radiomarelli); Sesto San Giovanni (MI)

Country:  Italy
Manufacturer / Brand:  Marelli (Radiomarelli); Sesto San Giovanni (MI)
Year: 1965 ?? Category: Car Radio, perhaps also + sound player/recorder
Semiconductors (the count is only for transistors) Semiconductors present. AD149 AD149
Main principle Super-Heterodyne (Super in general)
Wave bands Broadcast (MW) and Long Wave.
Details
Power type and voltage Storage Battery for all (e.g. for car radios and amateur radios) / 12 Volt
Loudspeaker - This model requires external speaker(s).
Power out 5 W (unknown quality)
from Radiomuseum.org Model: Sconosciuto/Unknown - Marelli Radiomarelli; Sesto
Material Metal case
Shape Chassis only or for «building in»
Dimensions (WHD) 160 x 47 x 165 mm / 6.3 x 1.9 x 6.5 inch
Net weight (2.2 lb = 1 kg) 1.4 kg / 3 lb 1.3 oz (3.084 lb)

Model page created by Edoardo Sigismondo. See "Data change" for further contributors.



All listed radios etc. from Marelli (Radiomarelli); Sesto San Giovanni (MI)
Here you find 431 models, 319 with images and 247 with schematics for wireless sets etc. In French: TSF for Télégraphie sans fil.
