• Year
  • 1942–1944
  • Category
  • Broadcast Receiver - or past WW2 Tuner
  • Radiomuseum.org ID
  • 12337

Click on the schematic thumbnail to request the schematic as a free document.

 Technical Specifications

  • Number of Tubes
  • 4
  • Main principle
  • Superheterodyne (common); ZF/IF 473 kHz
  • Wave bands
  • Broadcast, Long Wave and Short Wave.
  • Power type and voltage
  • Alternating Current supply (AC)
  • Loudspeaker
  • Presumably Dynamic Loudspeaker (moving coil)
  • Material
  • Bakelite case
  • from Radiomuseum.org
  • Model: M174A - Mediator; La Chaux-de-Fonds
  • Dimensions (WHD)
  • 528 x 305 x 227 mm / 20.8 x 12 x 8.9 inch
  • Notes
  • Holzfront
  • Price in first year of sale
  • 398.00 SFr
  • External source of data
  • E. Erb 3-907007-36-0
  • Source of data
  • Radiokatalog Band 2, Ernst Erb
  • Circuit diagram reference
  • Die Tungsram-Tabellen führen das Modell auf.
