For model M263A, Mediator; La Chaux-de-Fonds

Country:  Switzerland
Manufacturer / Brand:  Mediator; La Chaux-de-Fonds
Year: 1950/1951 ? Category: Broadcast Receiver - or past WW2 Tuner
Valves / Tubes 5: ECH42 EAF42 EBC41 EL41 AZ41
schematic requested
Main principle Superheterodyne (common); ZF/IF 452 kHz
Tuned circuits 4 AM circuit(s)
Wave bands Broadcast, Long Wave and 2 x Short Wave.
Details
Power type and voltage Alternating Current supply (AC) / 110; 125; 145; 200; 220; 245 Volt
Loudspeaker Permanent Magnet Dynamic (PDyn) Loudspeaker (moving coil) / Ø 16 cm = 6.3 inch
Power out 4.8 W (unknown quality)
from Radiomuseum.org Model: M263A - Mediator; La Chaux-de-Fonds
Material Bakelite case
Shape Tablemodel, low profile (big size).
Dimensions (WHD) 445 x 305 x 200 mm / 17.5 x 12 x 7.9 inch
Net weight (2.2 lb = 1 kg) 7.8 kg / 17 lb 2.9 oz (17.181 lb)
Source of data - - Data from my own collection

Model page created by Jorge Ferreira da Silva. See "Data change" for further contributors.
