M26A
Médiator; Paris
- Country
- France
- Manufacturer / Brand
- Médiator; Paris
- Year
- 1955
- Category
- Broadcast Receiver - or past WW2 Tuner
- Radiomuseum.org ID
- 208854
Click on the schematic thumbnail to request the schematic as a free document.
- Number of Tubes
- 6
- Main principle
- Superheterodyne (common); ZF/IF 455 kHz; 2 AF stage(s)
- Tuned circuits
- 6 AM circuit(s)
- Wave bands
- Broadcast, Long Wave and 2 x Short Wave.
- Power type and voltage
- Alternating Current supply (AC) / 110; 125; 145; 225; 245 Volt
- Loudspeaker
- Permanent Magnet Dynamic (PDyn) Loudspeaker (moving coil) / Ø 17 cm = 6.7 inch
- Material
- Wooden case
- from Radiomuseum.org
- Model: M26A - Médiator; Paris
- Shape
- Tablemodel with Push Buttons.
- Dimensions (WHD)
- 410 x 310 x 205 mm / 16.1 x 12.2 x 8.1 inch
- Notes
-
4 gammes d'ondes: OC de 16.7 à 41.10 m, BE (bande étalée) de 40 à 51.70 m, PO de 187 à 573,6 m, et GO de 1090 à 2000 m. Contre-réaction, réglage de tonalité progressif. Cadre antiparasite à air incorporé orientable. Prise PU.
Coffret noyer verni avec décor polystyrène or et ivoire.
Équivalent au Atlantic A62A.
- Net weight (2.2 lb = 1 kg)
- 7 kg / 15 lb 6.7 oz (15.419 lb)
- Mentioned in
- -- Original-techn. papers.
- Literature/Schematics (1)
- -- Original prospect or advert
- Author
- Model page created by Dietrich Grötzer. See "Data change" for further contributors.
