E35 neu

E35; Mende - Radio H. (ID = 2025452) Radio E35; Mende - Radio H. (ID = 2339921) Radio
Use red slider bar for more.
E35; Mende - Radio H. (ID = 2025452) Radio
Mende - Radio H.: E35 [Radio] ID = 2025452 918x635
Select picture or schematic to display from thumbnails on the right and click for download.
For model E35 neu, Mende - Radio H. Mende & Co. GmbH, Dresden:
ebay 182261371002, antiksalon2016.

Country:  Germany
Manufacturer / Brand:  Mende - Radio H. Mende & Co. GmbH, Dresden
Brand

System Günther
Year: 1927/1928 Category: Broadcast Receiver - or past WW2 Tuner
Valves / Tubes 2: RE144 RE064
Main principle TRF with regeneration; 1 Special; 1 AF stage(s); Reflex
Tuned circuits 2 AM circuit(s)
Wave bands Broadcast (MW) and Long Wave.
Details
Power type and voltage Storage and/or dry batteries / 90+4 Volt
Loudspeaker - For headphones or amp.
Power out
from Radiomuseum.org Model: E35 [neu] - Mende - Radio H. Mende & Co.
Material Wooden case, TUBES VISIBLE.
Shape Tablemodel, slant panel.
Dimensions (WHD) 330 x 250 x 185 mm / 13 x 9.8 x 7.3 inch
Notes plus unten l+r Feineinsteller; 200-200m; Reflex
Net weight (2.2 lb = 1 kg) 3.8 kg / 8 lb 5.9 oz (8.37 lb)
Price in first year of sale 131.00 RM +
Source of data Kat. Radio Schnorr 1927/28 / Radiokatalog Band 1, Ernst Erb
Picture reference Eine Abbildung findet sich im Doppelband "Radio von gestern"


All listed radios etc. from Mende - Radio H. Mende & Co. GmbH, Dresden
Here you find 309 models, 279 with images and 202 with schematics for wireless sets etc. In French: TSF for Télégraphie sans fil.
