For model Tongenerator, Mende - Radio H. Mende & Co. GmbH, Dresden:
D_Mende_Tong. 132_

Country:  Germany
Manufacturer / Brand:  Mende - Radio H. Mende & Co. GmbH, Dresden
Brand

System Günther
Year: 1946 ? Category: Service- or Lab Equipment
Valves / Tubes 3: RV12P4000 RV12P4000 RGN354
Wave bands - without
Details
Power type and voltage Alternating Current supply (AC) / 220 Volt
Loudspeaker - For headphones or amp.
Power out
from Radiomuseum.org Model: Tongenerator - Mende - Radio H. Mende & Co.
Material Various materials
Shape Tablemodel, with any shape - general.
Dimensions (WHD) 347 x 244 x 265 mm / 13.7 x 9.6 x 10.4 inch
Notes Aufgebaut aus alten Wehrmachtsteilen, 0 - 500 Hz umschaltbar auf 0 - 10 kHz, frontseitig angenietetes Typenschild, Panzerholzkasten; Das Gerät mit der frontseitigen Seriennummer "132" ist am Chassis als "Muster" bezeichnet, weiters ist ein Seriengerät Nr. "148" bekannt.
Net weight (2.2 lb = 1 kg) 6 kg / 13 lb 3.5 oz (13.216 lb)
Source of data -- Collector info (Sammler)

Model page created by a member from A. See "Data change" for further contributors.
