U2007

U2007; MESTRO, Fabrik (ID = 947684) Power-S
U2007; MESTRO, Fabrik (ID = 290194) Power-S U2007; MESTRO, Fabrik (ID = 290195) Power-S
U2007; MESTRO, Fabrik (ID = 947675) Power-S U2007; MESTRO, Fabrik (ID = 947676) Power-S
U2007; MESTRO, Fabrik (ID = 947677) Power-S U2007; MESTRO, Fabrik (ID = 1277350) Power-S
U2007; MESTRO, Fabrik (ID = 2307779) Power-S U2007; MESTRO, Fabrik (ID = 2307780) Power-S
U2007; MESTRO, Fabrik (ID = 2307781) Power-S U2007; MESTRO, Fabrik (ID = 2307782) Power-S
Use red slider bar for more.
U2007; MESTRO, Fabrik (ID = 290194) Power-S
MESTRO, Fabrik: U2007 [Power-S] ID = 290194 933x699
Select picture or schematic to display from thumbnails on the right and click for download.
For model U2007, MESTRO, Fabrik elektrischer Geräte; Köln

Country:  Germany
Manufacturer / Brand:  MESTRO, Fabrik elektrischer Geräte; Köln
Year: 1940 ? Category: Power supply/conditioner or battery or charger
Valves / Tubes 1: RGN354
Semiconductors (the count is only for transistors) Tr.Gl.=Metal-rectif.
Wave bands - without
Details Power Supply (not only Batt.El.)
Power type and voltage Alternating Current supply (AC) / 110; 220 Volt
Loudspeaker - - No sound reproduction output.
Power out
from Radiomuseum.org Model: U2007 - MESTRO, Fabrik elektrischer
Material Metal case
Shape Chassis only or for «building in»
Dimensions (WHD) 225 x 85 x 160 mm / 8.9 x 3.3 x 6.3 inch
Notes Ausgangs-Spannungen: 120 V, 2 V und -4,5 V (über Trockengleichrichter).
Net weight (2.2 lb = 1 kg) 3.5 kg / 7 lb 11.3 oz (7.709 lb)

Model page created by Albrecht Schwaderer. See "Data change" for further contributors.
