- Country
- Germany
- Manufacturer / Brand
- Metz Transformatoren- und Apparatefabrik (ex TAM), Fürth
- Year
- 1954 ?
- Category
- Broadcast Receiver - or past WW2 Tuner
- Radiomuseum.org ID
- 274871
Quelle: ebay.de, #321899355648
Quelle: ebay.de, #321899355648
Quelle: ebay.de, #321899355648
Quelle: ebay.de, #321899355648
- Number of Tubes
- 5
- Number of Transistors
- Semiconductors
- Tr.Gl.=Metal-rectif.
- Main principle
- Superheterodyne (common); Export model
- Tuned circuits
- 6 AM circuit(s)
- Wave bands
- Broadcast, Long Wave and more than two Short Wave bands.
- Power type and voltage
- Alternating Current supply (AC) / 110; 125; 150; 220; 240 Volt
- Loudspeaker
- 3 Loudspeakers
- Material
- Wooden case
- from Radiomuseum.org
- Model: 204 Exp. KW - Metz Transformatoren- und
- Shape
- Tablemodel with Push Buttons.
- Notes
-
Metz 204 Exp. KW ist ein 5-Röhren Wechselstrom-Super für den Export.
Empfangsbereiche:
- LW 150 ...... 400 kHz
- MW 515 .... 1620 kHz
- KW 1 14,2.. 18,5 MHz (19 m und 16 m Band)
- KW 2 6,5 ... 12,6 MHz (41 m, 31m und 25 m Band)
- KW 3 2,2 ... 6,6 MHz (125 m, 90 m, 60 m und 49 m Band)
- Author
- Model page created by Bernhard Nagel. See "Data change" for further contributors.
