Super Minx 573U

Super Minx 573U; Minerva-Radio (ID = 20243) Radio

Super Minx 573U; Minerva-Radio (ID = 910564) Radio
Super Minx 573U; Minerva-Radio (ID = 201079) Radio Super Minx 573U; Minerva-Radio (ID = 201080) Radio
Super Minx 573U; Minerva-Radio (ID = 37534) Radio Super Minx 573U; Minerva-Radio (ID = 1716920) Radio
Super Minx 573U; Minerva-Radio (ID = 1716921) Radio Super Minx 573U; Minerva-Radio (ID = 1716922) Radio
Super Minx 573U; Minerva-Radio (ID = 1716923) Radio
Use red slider bar for more.
Super Minx 573U; Minerva-Radio (ID = 201079) Radio
Minerva-Radio: Super Minx 573U [Radio] ID = 201079 679x487
Select picture or schematic to display from thumbnails on the right and click for download.
For model Super Minx 573U, Minerva-Radio (Radiola-Radioapparate und Bestandteile W. Wohleber & Co) ; Wien

Country:  Austria
Manufacturer / Brand:  Minerva-Radio (Radiola-Radioapparate und Bestandteile W. Wohleber & Co) ; Wien
Year: 1956/1957 Category: Broadcast Receiver - or past WW2 Tuner
Valves / Tubes 7: UCC85 UCH81 UF85 UABC80 UM80 UL84 UY85
Semiconductors (the count is only for transistors) NTK
Main principle Superheterodyne (common)
Tuned circuits 6 AM circuit(s)
Wave bands Broadcast, Long Wave and FM or UHF.
Details
Power type and voltage AC/DC-set / 130, 150, 220 Volt
Loudspeaker Permanent Magnet Dynamic (PDyn) Loudspeaker (moving coil)
Power out
from Radiomuseum.org Model: Super Minx 573U - Minerva-Radio Radiola-
Material Wooden case
Shape Tablemodel with Push Buttons.
Notes 2 Ausführungen:
Umschaltbar für 130V und 220V
Umschaltbar für 150V und 220V.
Price in first year of sale 1'480.00 ATS
External source of data E. Erb 3-907007-36-0
Source of data Radiokatalog Band 2, Ernst Erb
Literature/Schematics (1) -- Original-techn. papers.


All listed radios etc. from Minerva-Radio (Radiola-Radioapparate und Bestandteile W. Wohleber & Co) ; Wien
Here you find 627 models, 557 with images and 443 with schematics for wireless sets etc. In French: TSF for Télégraphie sans fil.
