Taormina 525/4

Taormina 525/4; Minerva Ital-Minerva (ID = 340214) Radio
Taormina 525/4; Minerva Ital-Minerva (ID = 1354733) Radio Taormina 525/4; Minerva Ital-Minerva (ID = 1354734) Radio
Taormina 525/4; Minerva Ital-Minerva (ID = 1354735) Radio Taormina 525/4; Minerva Ital-Minerva (ID = 1354736) Radio
Taormina 525/4; Minerva Ital-Minerva (ID = 1354737) Radio Taormina 525/4; Minerva Ital-Minerva (ID = 1354741) Radio
Taormina 525/4; Minerva Ital-Minerva (ID = 1744423) Radio Taormina 525/4; Minerva Ital-Minerva (ID = 1744424) Radio
Taormina 525/4; Minerva Ital-Minerva (ID = 1748012) Radio Taormina 525/4; Minerva Ital-Minerva (ID = 1748013) Radio
Use red slider bar for more.
Taormina 525/4; Minerva Ital-Minerva (ID = 1354733) Radio
Minerva Ital-Minerva: Taormina 525/4 [Radio] ID = 1354733 933x527
Select picture or schematic to display from thumbnails on the right and click for download.
For model Taormina 525/4, Minerva (Ital-Minerva); Milano

Country:  Italy
Manufacturer / Brand:  Minerva (Ital-Minerva); Milano
alternative name

Cozzi Luigi Dell'Aquila
Year: 1952–1954 Category: Broadcast Receiver - or past WW2 Tuner
Valves / Tubes 6: UCH42 UF41 UBC41 UL41 EM4 UY41
Main principle Superheterodyne (common); ZF/IF 468 kHz
Wave bands Broadcast plus more than 2 Short Wave bands.
Details
Power type and voltage Alternating Current supply (AC) / 110; 125; 140; 160; 220 Volt
Loudspeaker Presumably Dynamic Loudspeaker (moving coil)
Power out 2.5 W (unknown quality)
from Radiomuseum.org Model: Taormina 525/4 - Minerva Ital-Minerva; Milano
Material Wooden case
Shape Tablemodel, low profile (big size).
Dimensions (WHD) 590 x 320 x 220 mm / 23.2 x 12.6 x 8.7 inch
Notes Gamme d'onda: medie e 3 corte.
Wave bands: BC and 3x SW.
Source of data Guida Pratica Antique Radio (1) 1999
Literature/Schematics (1) -- Schematic

Model page created by Alessandro De Poi. See "Data change" for further contributors.
