Lero UCM601/2

Lero UCM601/2; Mivar VAR; Milano (ID = 639604) Radio
Lero UCM601/2; Mivar VAR; Milano (ID = 424586) Radio Lero UCM601/2; Mivar VAR; Milano (ID = 424589) Radio
Lero UCM601/2; Mivar VAR; Milano (ID = 424587) Radio Lero UCM601/2; Mivar VAR; Milano (ID = 757749) Radio
Lero UCM601/2; Mivar VAR; Milano (ID = 959908) Radio Lero UCM601/2; Mivar VAR; Milano (ID = 966319) Radio
Lero UCM601/2; Mivar VAR; Milano (ID = 1113872) Radio Lero UCM601/2; Mivar VAR; Milano (ID = 1140953) Radio
Lero UCM601/2; Mivar VAR; Milano (ID = 1140954) Radio Lero UCM601/2; Mivar VAR; Milano (ID = 1140956) Radio
Use red slider bar for more.
Lero UCM601/2; Mivar VAR; Milano (ID = 424586) Radio
Mivar VAR; Milano: Lero UCM601/2 [Radio] ID = 424586 933x389
Select picture or schematic to display from thumbnails on the right and click for download.
For model Lero UCM601/2, Mivar (VAR); Milano

Country:  Italy
Manufacturer / Brand:  Mivar (VAR); Milano
Year: 1958 Category: Broadcast Receiver - or past WW2 Tuner
Valves / Tubes 6: ECC85 ECH81 EF89 EABC80 UL84 UY85
Main principle Superheterodyne (common)
Wave bands Broadcast (BC) and FM or UHF.
Details
Power type and voltage Alternating Current supply (AC) / 110-240 Volt
Loudspeaker Permanent Magnet Dynamic (PDyn) Loudspeaker (moving coil) - elliptical / Ø 9 cm = 3.5 inch
Power out 3 W (unknown quality)
from Radiomuseum.org Model: Lero UCM601/2 - Mivar VAR; Milano
Material Moulded (Bakelite or Plastics)
Shape Tablemodel with Push Buttons.
Dimensions (WHD) 370 x 140 x 110 mm / 14.6 x 5.5 x 4.3 inch
Notes

Diverse varianti di colore. Denominata Lero UCM-601/2 (indicato sul pannello posteriore), era praticamente lo stesso chassis della Delo UCM-601/2 con un diverso mobile.

Come consolidata abitudine di Mivar, la Lero e la Delo sono state dotate sia delle UABC80 che della EABC80.

Possibilità di ricevere i canali TV VHF A e B.



Source of data Guida Pratica Antique Radio V (2003)

Model page created by Franco Antolini. See "Data change" for further contributors.



All listed radios etc. from Mivar (VAR); Milano
Here you find 117 models, 107 with images and 68 with schematics for wireless sets etc. In French: TSF for Télégraphie sans fil.






Forum contributions about this model
Mivar VAR; Milano: Lero UCM601/2
Threads: 1 | Posts: 1
Hits: 1429     Replies: 0
mivar: UCM601/2; Lero
Giuseppe Feniello
19.May.13
  1

Su alcuni esemplari la EABC80 è sostituita dalla UABC80, il filamento di questa è in serie con quello della UL84 e della UY85, la presa sull'autotrasformatore è alla uscita a 110V.
