A362; Murphy Radio Ltd.; (ID = 351448) Radio
Murphy Radio Ltd.;: A362 [Radio] ID = 351448 495x402
Select picture or schematic to display from thumbnails on the right and click for download.
For model A362, Murphy Radio Ltd.; Welwyn Garden City

Country:  Great Britain (UK)
Manufacturer / Brand:  Murphy Radio Ltd.; Welwyn Garden City
Year: 1955 Category: Broadcast Receiver - or past WW2 Tuner
Valves / Tubes 6: UCC85 10C1 10F9 EABC80 10P14 U404
Main principle Superheterodyne (common); ZF/IF 470/10700 kHz; 2 AF stage(s)
Tuned circuits 6 AM circuit(s)     8 FM circuit(s)
Wave bands Broadcast, Long Wave and FM or UHF.
Details
Power type and voltage Alternating Current supply (AC) / 200-250 Volt
Loudspeaker Permanent Magnet Dynamic (PDyn) Loudspeaker (moving coil) / Ø 4 inch = 10.2 cm
Power out
from Radiomuseum.org Model: A362 - Murphy Radio Ltd.; Welwyn
Material Bakelite case
Shape Tablemodel without push buttons, Mantel/Midget/Compact up to 14
Dimensions (WHD) 14.5 x 10 x 8 inch / 368 x 254 x 203 mm
Notes

An AC mains AM/FM table radio in a compact bakelite cabinet with a perspex fascia/dial, covering MW (187-568 metres), LW (1000-2000 metres) and VHF (87.5-100 MHz). Sliding tone control on the back. Sockets for Earth, AM aerial, FM aerial and external loudspeaker. Released June 1955, price £18 8s 7d plus purchase tax.

Price in first year of sale 23.00 GBP
Mentioned in -- Original-techn. papers.
Literature/Schematics (1) Trader Service Sheet (suppl. of Wireless & El. Trader, etc.) (1377 dated 8 November 1958)
Literature/Schematics (2) Radio And Television Servicing books (R&TVS)

Model page created by Peter Hoddow. See "Data change" for further contributors.
