Brillant-Phono 102/20 Ch= 3938
Neckermann-Versand KG; Frankfurt a.M.
- Country
- Germany
- Manufacturer / Brand
- Neckermann-Versand KG; Frankfurt a.M.
- Year
- 1958 ?
- Category
- Broadcast Receiver - or past WW2 Tuner
- Radiomuseum.org ID
- 295617
-
- Brand: Twen Tone
- Number of Tubes
- 7
- Main principle
- Superheterodyne (common); ZF/IF 472/10700 kHz
- Tuned circuits
- 6 AM circuit(s) 9 FM circuit(s)
- Wave bands
- Broadcast, Long Wave and FM or UHF.
- Details
- Record Player (not changer)
- Power type and voltage
- Alternating Current supply (AC) / 110-220 Volt
- Loudspeaker
- 3 Loudspeakers
- Power out
- 4 W (unknown quality)
- Material
- Wooden case
- from Radiomuseum.org
- Model: Brillant-Phono 102/20 Ch= 3938 - Neckermann-Versand KG;
- Shape
- Tablemodel with Push Buttons.
- Dimensions (WHD)
- 460 x 330 x 330 mm / 18.1 x 13 x 13 inch
- Notes
-
Neckermann Brillant Phono 102/20 Chassis 3938 entspricht Brillant Phono 102/30 mit folgenden Abweichungen:
- Phono-Laufwerk Philips
- Phono-Eingang nach DIN 41524 (DIN Buchse)
- Literature/Schematics (1)
- - - Manufacturers Literature
- Author
- Model page created by João Luis Mendes Colaço. See "Data change" for further contributors.
