Super WR9661W Nr. 111/10

Super WR9661W Nr. 111/10; Neckermann-Versand (ID = 1047907) Radio
Super WR9661W Nr. 111/10; Neckermann-Versand (ID = 2512886) Radio Super WR9661W Nr. 111/10; Neckermann-Versand (ID = 2512891) Radio
Super WR9661W Nr. 111/10; Neckermann-Versand (ID = 2512890) Radio Super WR9661W Nr. 111/10; Neckermann-Versand (ID = 2512887) Radio
Super WR9661W Nr. 111/10; Neckermann-Versand (ID = 2512889) Radio Super WR9661W Nr. 111/10; Neckermann-Versand (ID = 2512894) Radio
Super WR9661W Nr. 111/10; Neckermann-Versand (ID = 833877) Radio Super WR9661W Nr. 111/10; Neckermann-Versand (ID = 834004) Radio
Super WR9661W Nr. 111/10; Neckermann-Versand (ID = 834009) Radio Super WR9661W Nr. 111/10; Neckermann-Versand (ID = 672316) Radio
Use red slider bar for more.
Super WR9661W Nr. 111/10; Neckermann-Versand (ID = 2512886) Radio
Neckermann-Versand: Super WR9661W Nr. 111/10 [Radio] ID = 2512886 1400x1074
Select picture or schematic to display from thumbnails on the right and click for download.
For model Super WR9661W Nr. 111/10, Neckermann-Versand KG; Frankfurt a.M.

Country:  Germany
Manufacturer / Brand:  Neckermann-Versand KG; Frankfurt a.M.
Brand

Twen Tone
Year: 1953–1955 Category: Broadcast Receiver - or past WW2 Tuner
Valves / Tubes 6: ECC81 ECH81 EF41 EABC80 EM34 EL41
Semiconductors (the count is only for transistors) B250C75
Main principle Superheterodyne (common); ZF/IF 468/10700 kHz
Tuned circuits 6 AM circuit(s)     9 FM circuit(s)
Wave bands Broadcast, Long Wave and FM or UHF.
Details
Power type and voltage Alternating Current supply (AC) / 110; 125; 220; 240 Volt
Loudspeaker Permanent Magnet Dynamic (PDyn) Loudspeaker (moving coil) / Ø 18 cm = 7.1 inch
Power out
from Radiomuseum.org Model: Super WR9661W Nr. 111/10 - Neckermann-Versand KG;
Material Wooden case
Shape Tablemodel with Push Buttons.
Dimensions (WHD) 495 x 350 x 225 mm / 19.5 x 13.8 x 8.9 inch
Notes

Klangregler und Baßschalter. Anschlüsse für Plattenspieler und Zweitlautsprecher (5 Ohm).

Hersteller: AWB (Apparate-Werk Bayern) für Neckermann Versand KG, Frankfurt/M.

Siehe auch WR9661W dort.

Erstes Neckermann Radio. Zugleich 1. Radio, das in Deutschland per Versandhandel geliefert wird. Erscheint erstmals im Kat. 141, der ab 1.11.1953 gültig wird. Bis 1955 in den Katalogen.

Siehe Funkgeschichte 131 von Mai / Juni 2000

Net weight (2.2 lb = 1 kg) 7.7 kg / 16 lb 15.4 oz (16.96 lb)
Price in first year of sale 187.00 DM
Mentioned in Neckermann-Katalog (Ausgabe 145 vom 1.9.1954)
Literature/Schematics (1) -- Schematic
Literature/Schematics (2) Neckermann-Katalog (Ausg. 141 vom 1.11.1953)
Literature/Schematics (3) Funkgeschichte der GFGF (Heft 131, Mai/Juni 2000)

Model page created by Heinz Parsche. See "Data change" for further contributors.
