Egmont W855 Export

Egmont W855; Nora; Berlin (ID = 2629995) Radio
Egmont W855; Nora; Berlin (ID = 267997) Radio Egmont W855; Nora; Berlin (ID = 267999) Radio
Egmont W855; Nora; Berlin (ID = 268001) Radio Egmont W855; Nora; Berlin (ID = 717223) Radio
Egmont W855; Nora; Berlin (ID = 2629989) Radio Egmont W855; Nora; Berlin (ID = 2629990) Radio
Egmont W855; Nora; Berlin (ID = 2629991) Radio Egmont W855; Nora; Berlin (ID = 2629993) Radio
Egmont W855; Nora; Berlin (ID = 2629994) Radio
Use red slider bar for more.
Egmont W855; Nora; Berlin (ID = 267997) Radio
Nora; Berlin: Egmont W855 [Radio] ID = 267997 933x699
Select picture or schematic to display from thumbnails on the right and click for download.
For model Egmont W855 Export, Nora; Berlin

Country:  Germany
Manufacturer / Brand:  Nora; Berlin
Year: 1951/1952 Category: Broadcast Receiver - or past WW2 Tuner
Valves / Tubes 6: ECH42 EBF15 EAF42 EL41 EM5 AZ41
Main principle Superheterodyne (common); ZF/IF 468 kHz
Tuned circuits 6 AM circuit(s)
Wave bands Broadcast plus 2 Short Wave bands.
Details
Power type and voltage Alternating Current supply (AC) / 110-240 Volt
Loudspeaker Permanent Magnet Dynamic (PDyn) Loudspeaker (moving coil)
Power out
from Radiomuseum.org Model: Egmont W855 [Export] - Nora; Berlin
Material Wooden case
Shape Tablemodel, low profile (big size).
Dimensions (WHD) 560 x 380 x 250 mm / 22 x 15 x 9.8 inch
Notes
Net weight (2.2 lb = 1 kg) 12 kg / 26 lb 6.9 oz (26.432 lb)
Source of data Radiokatalog Band 1, Ernst Erb


All listed radios etc. from Nora; Berlin
Here you find 621 models, 540 with images and 340 with schematics for wireless sets etc. In French: TSF for Télégraphie sans fil.
