Serenade W654 M

Serenade W654 M; Nora; Berlin (ID = 198040) Radio

Serenade W654 M; Nora; Berlin (ID = 198042) Radio

Serenade W654 M; Nora; Berlin (ID = 15727) Radio

Serenade W654 M; Nora; Berlin (ID = 15729) Radio

Serenade W654 M; Nora; Berlin (ID = 4397) Radio

Serenade W654 M; Nora; Berlin (ID = 876924) Radio

Serenade W654 M; Nora; Berlin (ID = 1143953) Radio
Serenade W654 M; Nora; Berlin (ID = 301078) Radio Serenade W654 M; Nora; Berlin (ID = 174708) Radio
Serenade W654 M; Nora; Berlin (ID = 1715648) Radio Serenade W654 M; Nora; Berlin (ID = 174707) Radio
Serenade W654 M; Nora; Berlin (ID = 996232) Radio Serenade W654 M; Nora; Berlin (ID = 996233) Radio
Serenade W654 M; Nora; Berlin (ID = 1541631) Radio Serenade W654 M; Nora; Berlin (ID = 1541632) Radio
Serenade W654 M; Nora; Berlin (ID = 1541633) Radio Serenade W654 M; Nora; Berlin (ID = 1541634) Radio
Use red slider bar for more.
Serenade W654 M; Nora; Berlin (ID = 301078) Radio
Nora; Berlin: Serenade W654 M [Radio] ID = 301078 800x600
Select picture or schematic to display from thumbnails on the right and click for download.
For model Serenade W654 M, Nora; Berlin

Country:  Germany
Manufacturer / Brand:  Nora; Berlin
Year: 1950/1951 Category: Broadcast Receiver - or past WW2 Tuner
Valves / Tubes 6: ECH42 EAF42 EAF42 EL41 EM4 or EM5 AZ41
Main principle Super-Heterodyne (Super in general); ZF/IF 473 kHz
Tuned circuits 6 AM circuit(s)
Wave bands Ready for FM, has Broadcast, Long Wave, Short wave.
Details
Power type and voltage Alternating Current supply (AC) / 110; 125; 150; 220; 240 Volt
Loudspeaker Permanent Magnet Dynamic (PDyn) Loudspeaker (moving coil) / Ø 21 cm = 8.3 inch
Power out
from Radiomuseum.org Model: Serenade W654 M - Nora; Berlin
Material Wooden case
Shape Tablemodel, low profile (big size).
Dimensions (WHD) 530 x 370 x 210 mm / 20.9 x 14.6 x 8.3 inch
Notes

UKW vorbereitet für UKW-Einsatz UKW-P.
Skalenlampe: 2x 18V/0,1A.

Im Katalog des Rundfunk-Grosshandels 1950/51 mit W654 M bezeichnet,
Rückwanddruck zeigt dagegen W654.

Net weight (2.2 lb = 1 kg) 10.7 kg / 23 lb 9.1 oz (23.568 lb)
Price in first year of sale 278.00 DM
Collectors' prices
Source of data Kat.d. Rundf.Gr.Handel 1950/51 / Radiokatalog Band 1, Ernst Erb
Circuit diagram reference Lange-Nowisch
Mentioned in Funkschau (5019)
Literature/Schematics (1) -- Original-techn. papers.


All listed radios etc. from Nora; Berlin
Here you find 614 models, 530 with images and 336 with schematics for wireless sets etc. In French: TSF for Télégraphie sans fil.






Forum contributions about this model
Nora; Berlin: Serenade W654 M
Threads: 1 | Posts: 1
Hits: 1484     Replies: 0
nora: W654M; Serenade
