For model Arabella-Stereo Ch= 5/683 Nussbaum, Nordmende, Norddeutsche Mende-Rundfunk GmbH (Sterling), Bremen-Hemelingen

Country:  Germany
Manufacturer / Brand:  Nordmende, Norddeutsche Mende-Rundfunk GmbH (Sterling), Bremen-Hemelingen
Year: 1964/1965 Category: Broadcast Receiver - or past WW2 Tuner
Valves / Tubes 12: ECC85 ECH81 EF89 EBF89 EM87 EF80 ECC83 ECC83 ECC83 ELL80 ELL80 EAM86
Main principle Super-Heterodyne (Super in general)
Tuned circuits 8 AM circuit(s)     12 FM circuit(s)
Wave bands Broadcast, Long Wave, Short Wave plus FM or UHF.
Details Changer (Record changer)
Power type and voltage Alternating Current supply (AC) / 110-240 Volt
Loudspeaker 4 Loudspeakers
Power out
from Radiomuseum.org Model: Arabella-Stereo Ch= 5/683 [Nussbaum] - Nordmende, Norddeutsche Mende-
Material Wooden case
Shape Console with Push Buttons.
Dimensions (WHD) 1360 x 800 x 395 mm / 53.5 x 31.5 x 15.6 inch
Notes

AM-ZF-Bandbreite umschaltbar;
Stereo-Decoder 184.218.12 eingebaut;
Stereo-NF-Verstärker mit 2 Gegentakt-Endstufen je 8,5 W;
Phono-Chassis = Dual 1011.

Net weight (2.2 lb = 1 kg) 48 kg / 105 lb 11.6 oz (105.727 lb)
Price in first year of sale 1'724.00 DM
External source of data Erb
Source of data Handbuch VDRG 1964/1965
Literature/Schematics (1) -- Original-techn. papers.
