Boheme C

Nordmende, Norddeutsche Mende-Rundfunk GmbH (Sterling), Bremen-Hemelingen

Data
Forum
Pictures
Collections

  • Year
  • 1962/1963 ?
  • Category
  • Broadcast Receiver - or past WW2 Tuner
  • Radiomuseum.org ID
  • 328243

 Technical Specifications

  • Number of Tubes
  • 6
  • Number of Transistors
  • Main principle
  • Superheterodyne (common); ZF/IF 460/10700 kHz; Export model
  • Tuned circuits
  • 6 AM circuit(s)     10 FM circuit(s)
  • Wave bands
  • Broadcast, 2 Short Wave plus FM or UHF.
  • Power type and voltage
  • Alternating Current supply (AC) / 60Hz, 115 Volt
  • Loudspeaker
  • Permanent Magnet Dynamic (PDyn) Loudspeaker (moving coil) - elliptical
  • Power out
  • 4 W (unknown quality)
  • Material
  • Wooden case
  • from Radiomuseum.org
  • Model: Boheme C - Nordmende, Norddeutsche Mende-
  • Shape
  • Tablemodel with Push Buttons.
  • Dimensions (WHD)
  • 440 x 270 x 235 mm / 17.3 x 10.6 x 9.3 inch
  • Notes

  • Nordmende Boheme C is an export model for the USA and Canada. The radio features these wave bands: FM 88 to 108 MHz, SW1, SW2 and BC 525 to 1620 kHz. The BC band has additional CD-marks to indicate the frequencies 640 and 1240 kHz of the US-Civil Defense.

    See also the German domestic model Boheme D13 Ch= 3/613

  • Net weight (2.2 lb = 1 kg)
  • 7.5 kg / 16 lb 8.3 oz (16.52 lb)
  • Author
  • Model page created by Bernhard Nagel. See "Data change" for further contributors.
