Parsifal-Stereo Z170 Ch= 2/616

Parsifal-Stereo Z170 Ch= 2/616; Nordmende, (ID = 40044) Radio

Parsifal-Stereo Z170 Ch= 2/616; Nordmende, (ID = 945465) Radio

Parsifal-Stereo Z170 Ch= 2/616; Nordmende, (ID = 945466) Radio

Parsifal-Stereo Z170 Ch= 2/616; Nordmende, (ID = 945467) Radio

Parsifal-Stereo Z170 Ch= 2/616; Nordmende, (ID = 945468) Radio

Parsifal-Stereo Z170 Ch= 2/616; Nordmende, (ID = 945469) Radio

Parsifal-Stereo Z170 Ch= 2/616; Nordmende, (ID = 991646) Radio
Parsifal-Stereo Z170 Ch= 2/616; Nordmende, (ID = 1316010) Radio Parsifal-Stereo Z170 Ch= 2/616; Nordmende, (ID = 584877) Radio
Parsifal-Stereo Z170 Ch= 2/616; Nordmende, (ID = 159088) Radio Parsifal-Stereo Z170 Ch= 2/616; Nordmende, (ID = 1316011) Radio
Parsifal-Stereo Z170 Ch= 2/616; Nordmende, (ID = 1017063) Radio Parsifal-Stereo Z170 Ch= 2/616; Nordmende, (ID = 750034) Radio
Parsifal-Stereo Z170 Ch= 2/616; Nordmende, (ID = 750036) Radio Parsifal-Stereo Z170 Ch= 2/616; Nordmende, (ID = 750033) Radio
Parsifal-Stereo Z170 Ch= 2/616; Nordmende, (ID = 16462) Radio Parsifal-Stereo Z170 Ch= 2/616; Nordmende, (ID = 584874) Radio
Use red slider bar for more.
Parsifal-Stereo Z170 Ch= 2/616; Nordmende, (ID = 1316010) Radio
Nordmende,: Parsifal-Stereo Z170 Ch= 2/616 [Radio] ID = 1316010 933x594
Select picture or schematic to display from thumbnails on the right and click for download.
For model Parsifal-Stereo Z170 Ch= 2/616, Nordmende, Norddeutsche Mende-Rundfunk GmbH (Sterling), Bremen-Hemelingen

Country:  Germany
Manufacturer / Brand:  Nordmende, Norddeutsche Mende-Rundfunk GmbH (Sterling), Bremen-Hemelingen
Year: 1961–1963 Category: Broadcast Receiver - or past WW2 Tuner
Valves / Tubes 8: ECC85 ECH81 EF89 EABC80 EM84 EBC81 EL84 EL84
Main principle Super-Heterodyne (Super in general); ZF/IF 460/10700 kHz
Tuned circuits 6 AM circuit(s)     10 FM circuit(s)
Wave bands Broadcast, Long Wave, Short Wave plus FM or UHF.
Details
Power type and voltage Alternating Current supply (AC) / 110; 125; 150; 220; 240 Volt
Loudspeaker 2 Loudspeakers
Power out
from Radiomuseum.org Model: Parsifal-Stereo Z170 Ch= 2/616 - Nordmende, Norddeutsche Mende-
Material Wooden case
Shape Tablemodel with Push Buttons.
Dimensions (WHD) 575 x 340 x 255 mm / 22.6 x 13.4 x 10 inch
Notes Stereo-NF-Verstärker mit 2 Endstufen je 3 W.
Net weight (2.2 lb = 1 kg) 11.7 kg / 25 lb 12.3 oz (25.771 lb)
Price in first year of sale 365.00 DM
Collectors' prices
External source of data Erb
Source of data HdB d.Rdf-& Ferns-GrH 1961/62
Literature/Schematics (1) -- Original-techn. papers.
