Polka 57 BN251A

Polka 57 BN251A; Philips Norway Norsk (ID = 1145142) Radio Polka 57 BN251A; Philips Norway Norsk (ID = 1145144) Radio
Polka 57 BN251A; Philips Norway Norsk (ID = 1145141) Radio Polka 57 BN251A; Philips Norway Norsk (ID = 1145143) Radio
Use red slider bar for more.
Polka 57 BN251A; Philips Norway Norsk (ID = 1145142) Radio
Philips Norway Norsk: Polka 57 BN251A [Radio] ID = 1145142 500x375
Select picture or schematic to display from thumbnails on the right and click for download.
For model Polka 57 BN251A, Philips Norway (Norsk A/S Philips - A/S Radio Industri); Oslo:
kaufport_sammlerservice 230729322572

Country:  Norway
Manufacturer / Brand:  Philips Norway (Norsk A/S Philips - A/S Radio Industri); Oslo
Year: 1956 Category: Broadcast Receiver - or past WW2 Tuner
Valves / Tubes 5: ECH81 EBF80 EBC41 EL84 EZ80
Main principle Superheterodyne (common)
Wave bands Broadcast, Long Wave and 2 x Short Wave.
Details
Power type and voltage Alternating Current supply (AC) / 130; 150; 230 Volt
Loudspeaker Permanent Magnet Dynamic (PDyn) Loudspeaker (moving coil) / Ø 20 cm = 7.9 inch
Power out
from Radiomuseum.org Model: Polka 57 BN251A - Philips Norway Norsk A/S
Material Wooden case
Shape Tablemodel, low profile (big size).
Dimensions (WHD) 380 x 260 x 180 mm / 15 x 10.2 x 7.1 inch
Price in first year of sale 366.00 NKr
Mentioned in Norwegian Historical Radio Society

Model page created by Ernst Rykkje. See "Data change" for further contributors.
