Lumina L691A

Lumina L691A; Novak also Pontiac; (ID = 1292594) Radio
Use red slider bar for more.
Lumina L691A; Novak also Pontiac; (ID = 1292594) Radio
Select picture or schematic to display from thumbnails on the right and click for download.

Country:  Belgium
Manufacturer / Brand:  Novak (also Pontiac); Bruxelles
Year: 1950 ?? Category: Broadcast Receiver - or past WW2 Tuner
Valves / Tubes 6: ECH41 EAF41 EAF41 EL41 EM4 AZ41
Main principle Superheterodyne (common); 2 AF stage(s)
Tuned circuits 6 AM circuit(s)
Wave bands Broadcast, Long Wave and Short Wave.
Details
Power type and voltage Alternating Current supply (AC) / 110-240 Volt
Loudspeaker Permanent Magnet Dynamic (PDyn) Loudspeaker (moving coil) / Ø 6 inch = 15.2 cm
Power out
from Radiomuseum.org Model: Lumina L691A - Novak also Pontiac; Bruxelles
Source of data -- Schematic

Model page created by Georges Van Campenhout. See "Data change" for further contributors.
