• Year
  • 1949/1950
  • Category
  • Broadcast Receiver - or past WW2 Tuner
  • Radiomuseum.org ID
  • 199434

Click on the schematic thumbnail to request the schematic as a free document.

 Technical Specifications

  • Number of Tubes
  • 6
  • Main principle
  • Superheterodyne (common); ZF/IF 452 kHz
  • Wave bands
  • Broadcast, Long Wave and 2 x Short Wave.
  • Power type and voltage
  • Alternating Current supply (AC) / 110; 125; 145; 200; 220; 245 Volt
  • Loudspeaker
  • Permanent Magnet Dynamic (PDyn) Loudspeaker (moving coil) / Ø 21 cm = 8.3 inch
  • Material
  • Bakelite case
  • from Radiomuseum.org
  • Model: H284A - NSF Nederlandsche
  • Shape
  • Tablemodel, low profile (big size).
  • Dimensions (WHD)
  • 460 x 320 x 205 mm / 18.1 x 12.6 x 8.1 inch
  • Net weight (2.2 lb = 1 kg)
  • 8.8 kg / 19 lb 6.1 oz (19.383 lb)
  • Price in first year of sale
  • 280.00 Hfl
  • Source of data
  • -- Collector info (Sammler)
  • Author
  • Model page created by Gidi Verheijen. See "Data change" for further contributors.
