AM/FM Stereo Synthesizer Receiver PR-90

AM/FM Stereo Synthesizer Receiver PR-90; Omega brand?; where (ID = 1469052) Radio AM/FM Stereo Synthesizer Receiver PR-90; Omega brand?; where (ID = 1469056) Radio
AM/FM Stereo Synthesizer Receiver PR-90; Omega brand?; where (ID = 1469057) Radio AM/FM Stereo Synthesizer Receiver PR-90; Omega brand?; where (ID = 1469058) Radio
AM/FM Stereo Synthesizer Receiver PR-90; Omega brand?; where (ID = 1469059) Radio AM/FM Stereo Synthesizer Receiver PR-90; Omega brand?; where (ID = 1469060) Radio
AM/FM Stereo Synthesizer Receiver PR-90; Omega brand?; where (ID = 1469062) Radio AM/FM Stereo Synthesizer Receiver PR-90; Omega brand?; where (ID = 1469063) Radio
AM/FM Stereo Synthesizer Receiver PR-90; Omega brand?; where (ID = 1469064) Radio AM/FM Stereo Synthesizer Receiver PR-90; Omega brand?; where (ID = 1469065) Radio
Use red slider bar for more.
AM/FM Stereo Synthesizer Receiver PR-90; Omega brand?; where (ID = 1469052) Radio
Omega brand?; where: AM/FM Stereo Synthesizer Receiver PR-90 [Radio] ID = 1469052 933x1329
Select picture or schematic to display from thumbnails on the right and click for download.
For model AM/FM Stereo Synthesizer Receiver PR-90, Omega (brand?); where?

Country:  unknown Country
Manufacturer / Brand:  Omega (brand?); where?
Year: 1993 ? Category: Broadcast Receiver - or past WW2 Tuner
Semiconductors (the count is only for transistors) TC9308 TA8132 TDA2822 TA7358 TD6134
Main principle PLL, Phase-locked loop
Wave bands Broadcast (BC) and FM or UHF.
Details
Power type and voltage Dry Batteries / 2 x 1.5 Volt
Loudspeaker Permanent Magnet Dynamic (PDyn) Loudspeaker (moving coil) / Ø 4.2 cm = 1.7 inch
Power out 0.1 W (max.)
from Radiomuseum.org Model: AM/FM Stereo Synthesizer Receiver PR-90 - Omega brand?; where?
Material Modern plastics (no Bakelite or Catalin)
Shape Very small Portable or Pocket-Set (Handheld) < 8 inch.
Dimensions (WHD) 60 x 105 x 20 mm / 2.4 x 4.1 x 0.8 inch
Notes

The earphone cable acts as a FM antenna.



Net weight (2.2 lb = 1 kg) 0.1 kg / 0 lb 3.5 oz (0.22 lb)

Model page created by Jose Mesquita. See "Data change" for further contributors.
