420U 010

420U; Orion; Budapest (ID = 799811) Radio

420U; Orion; Budapest (ID = 1896763) Radio
420U; Orion; Budapest (ID = 383753) Radio 420U; Orion; Budapest (ID = 1529557) Radio
420U; Orion; Budapest (ID = 1530693) Radio 420U; Orion; Budapest (ID = 1705037) Radio
420U; Orion; Budapest (ID = 1529558) Radio 420U; Orion; Budapest (ID = 1530695) Radio
420U; Orion; Budapest (ID = 2241617) Radio
Use red slider bar for more.
420U; Orion; Budapest (ID = 383753) Radio
Orion; Budapest: 420U [Radio] ID = 383753 472x397
Select picture or schematic to display from thumbnails on the right and click for download.
For model 420U 010, Orion; Budapest:
Thanks for technical assistance Első Zalai Rádiómúzeum Alapítvány ( radio-muzeum.hu), First Zala County Radio Museum Foundation, Hungary, Zalaegerszeg.

Country:  Hungary
Manufacturer / Brand:  Orion; Budapest
Year: 1954 Category: Broadcast Receiver - or past WW2 Tuner
Valves / Tubes 5: UCH42 UAF42 UAF42 UL41 UY41
Main principle Superheterodyne (common); ZF/IF 473,6 kHz
Tuned circuits 6 AM circuit(s)
Wave bands Broadcast, Long Wave and 2 x Short Wave.
Details
Power type and voltage AC/DC-set / 110/220 Volt
Loudspeaker Permanent Magnet Dynamic (PDyn) Loudspeaker (moving coil) / Ø 16 cm = 6.3 inch
Power out 2 W (unknown quality)
from Radiomuseum.org Model: 420U [010] - Orion; Budapest
Material Wooden case
Shape Tablemodel, low profile (big size).
Dimensions (WHD) 360 x 250 x 200 mm / 14.2 x 9.8 x 7.9 inch
Net weight (2.2 lb = 1 kg) 6 kg / 13 lb 3.5 oz (13.216 lb)
Price in first year of sale 1'500.00 HUF
Mentioned in Rádiókészülékek Kapcsolásai 1936-56

Model page created by Folkert Rothe. See "Data change" for further contributors.
