AR 301 020

AR 301; Orion; Budapest (ID = 1717177) Radio

AR 301; Orion; Budapest (ID = 1717178) Radio

AR 301; Orion; Budapest (ID = 1896826) Radio
AR 301; Orion; Budapest (ID = 529664) Radio AR 301; Orion; Budapest (ID = 1510742) Radio
AR 301; Orion; Budapest (ID = 1653308) Radio AR 301; Orion; Budapest (ID = 1653309) Radio
AR 301; Orion; Budapest (ID = 1845467) Radio AR 301; Orion; Budapest (ID = 1845468) Radio
AR 301; Orion; Budapest (ID = 1845469) Radio AR 301; Orion; Budapest (ID = 1845470) Radio
AR 301; Orion; Budapest (ID = 2236402) Radio AR 301; Orion; Budapest (ID = 2236403) Radio
Use red slider bar for more.
AR 301; Orion; Budapest (ID = 529664) Radio
Orion; Budapest: AR 301 [Radio] ID = 529664 555x449
Select picture or schematic to display from thumbnails on the right and click for download.
For model AR 301 020, Orion; Budapest:
A magyar rádiózás története CD.

Country:  Hungary
Manufacturer / Brand:  Orion; Budapest
Year: 1956/1957 Category: Broadcast Receiver - or past WW2 Tuner
Valves / Tubes 4: ECH81 EBF80 EL84 EZ80
Main principle Super-Heterodyne (Super in general); ZF/IF 473,6 kHz
Wave bands Broadcast plus 2 Short Wave bands.
Details
Power type and voltage Alternating Current supply (AC) / 110; 127; 150; 220; 240 Volt
Loudspeaker Permanent Magnet Dynamic (PDyn) Loudspeaker (moving coil) / Ø 13 cm = 5.1 inch
Power out 2 W (unknown quality)
from Radiomuseum.org Model: AR 301 [020] - Orion; Budapest
Material Wooden case
Shape Tablemodel with Push Buttons.
Notes SW1:5,7-11,5 MHz. SW2:11,5-18,5 MHz.
Net weight (2.2 lb = 1 kg) 5 kg / 11 lb 0.2 oz (11.013 lb)
Price in first year of sale 1'100.00 Forint
Literature/Schematics (1) Radio es Televizio Vevö keszülekek, 1956-57

Model page created by Sandor Selyem-Tóth. See "Data change" for further contributors.



All listed radios etc. from Orion; Budapest
Here you find 991 models, 847 with images and 353 with schematics for wireless sets etc. In French: TSF for Télégraphie sans fil.
