AR 302; Orion; Budapest (ID = 530287) Radio
Orion; Budapest: AR 302 [Radio] ID = 530287 555x427
Select picture or schematic to display from thumbnails on the right and click for download.
For model AR 302 030, Orion; Budapest:
A magyar rádiózás története, CD.

Country:  Hungary
Manufacturer / Brand:  Orion; Budapest
Year: 1956/1957 Category: Broadcast Receiver - or past WW2 Tuner
Valves / Tubes 4: ECH81 EBF80 EL84 EZ80
Main principle Super-Heterodyne (Super in general); ZF/IF 473,6 kHz
Wave bands Broadcast plus 2 Short Wave bands.
Details
Power type and voltage Alternating Current supply (AC) / 110; 127; 150; 220; 240 Volt
Loudspeaker Permanent Magnet Dynamic (PDyn) Loudspeaker (moving coil) - elliptical / Ø 16 cm = 6.3 inch
Power out 2 W (unknown quality)
from Radiomuseum.org Model: AR 302 [030] - Orion; Budapest
Material Wooden case
Shape Tablemodel with Push Buttons.
Dimensions (WHD) 500 x 350 x 200 mm / 19.7 x 13.8 x 7.9 inch
Net weight (2.2 lb = 1 kg) 6 kg / 13 lb 3.5 oz (13.216 lb)
Literature/Schematics (1) Radio es Televizio Vevö keszülekek, 1956-57

Model page created by Sandor Selyem-Tóth. See "Data change" for further contributors.
