Belgame AR 205 - Export 14C

Belgame AR 205 - Export 14C; Orion; Budapest (ID = 1717467) Radio
Belgame AR 205 - Export 14C; Orion; Budapest (ID = 1043533) Radio Belgame AR 205 - Export 14C; Orion; Budapest (ID = 1043534) Radio
Belgame AR 205 - Export 14C; Orion; Budapest (ID = 1043535) Radio Belgame AR 205 - Export 14C; Orion; Budapest (ID = 1043536) Radio
Belgame AR 205 - Export 14C; Orion; Budapest (ID = 1043537) Radio Belgame AR 205 - Export 14C; Orion; Budapest (ID = 1043538) Radio
Belgame AR 205 - Export 14C; Orion; Budapest (ID = 1043540) Radio Belgame AR 205 - Export 14C; Orion; Budapest (ID = 1043541) Radio
Use red slider bar for more.
Belgame AR 205 - Export 14C; Orion; Budapest (ID = 1043533) Radio
Orion; Budapest: Belgame AR 205 - Export 14C [Radio] ID = 1043533 800x590
Select picture or schematic to display from thumbnails on the right and click for download.
For model Belgame AR 205 - Export 14C, Orion; Budapest:
STS Archív. Thanks for technical assistance Első Zalai Rádiómúzeum Alapítvány ( radio-muzeum.hu), First Zala County Radio Museum Foundation, Hungary, Zalaegerszeg.

Country:  Hungary
Manufacturer / Brand:  Orion; Budapest
Year: 1958 Category: Broadcast Receiver - or past WW2 Tuner
Valves / Tubes 4: ECH81 EBF80 EL84 EZ80
Main principle Superheterodyne (common); ZF/IF 473,6 kHz
Wave bands Broadcast and Short Wave (SW).
Details
Power type and voltage Alternating Current supply (AC) / 110; 220 Volt
Loudspeaker Permanent Magnet Dynamic (PDyn) Loudspeaker (moving coil) / Ø 13 cm = 5.1 inch
Power out
from Radiomuseum.org Model: Belgame AR 205 - Export 14C - Orion; Budapest
Material Bakelite case
Shape Tablemodel, Mantel/Midget/Compact up to 14" width, but not a Portable (See power data. Sometimes with handle but for mains only).
Dimensions (WHD) 330 x 250 x 200 mm / 13 x 9.8 x 7.9 inch
Notes Marineband: 25-80 m.
Net weight (2.2 lb = 1 kg) 5 kg / 11 lb 0.2 oz (11.013 lb)
Price in first year of sale 900.00 HUF
Literature/Schematics (1) Radio es Televizio Vevö Keszülekek, 1958-59

Model page created by Sandor Selyem-Tóth. See "Data change" for further contributors.
