Nostalgieradio AR-75

Nostalgieradio AR-75; Orion; Budapest (ID = 1433200) Radio
Nostalgieradio AR-75; Orion; Budapest (ID = 2209347) Radio Nostalgieradio AR-75; Orion; Budapest (ID = 2209352) Radio
Nostalgieradio AR-75; Orion; Budapest (ID = 2209349) Radio Nostalgieradio AR-75; Orion; Budapest (ID = 2209351) Radio
Nostalgieradio AR-75; Orion; Budapest (ID = 433840) Radio Nostalgieradio AR-75; Orion; Budapest (ID = 433843) Radio
Nostalgieradio AR-75; Orion; Budapest (ID = 433841) Radio Nostalgieradio AR-75; Orion; Budapest (ID = 433842) Radio
Nostalgieradio AR-75; Orion; Budapest (ID = 433844) Radio Nostalgieradio AR-75; Orion; Budapest (ID = 433858) Radio
Use red slider bar for more.
Nostalgieradio AR-75; Orion; Budapest (ID = 2209347) Radio
Orion; Budapest: Nostalgieradio AR-75 [Radio] ID = 2209347 1400x1759
Select picture or schematic to display from thumbnails on the right and click for download.
For model Nostalgieradio AR-75, Orion; Budapest:
Perneky Sándor - Rádiómúzeum Alapítvány, Verőce, Hungary, radiomuzeum.hu

Country:  Hungary
Manufacturer / Brand:  Orion; Budapest
Year: 1988 Category: Broadcast Receiver - or past WW2 Tuner
Semiconductors (the count is only for transistors) 1: BF225 or. BF199 TDA7000 TBA800 or. TBA810
Main principle Super-Heterodyne (Super in general); ZF/IF 70 kHz
Wave bands FM Broadcast Band Only
Details
Power type and voltage Alternating Current supply (AC) / 220 Volt
Loudspeaker Permanent Magnet Dynamic (PDyn) Loudspeaker (moving coil) - elliptical
Power out
from Radiomuseum.org Model: Nostalgieradio AR-75 - Orion; Budapest
Material Wooden case
Shape Table-Cathedral-Type (upright, round top or gothic arch, not rounded edges only).
Dimensions (WHD) 350 x 430 x 225 mm / 13.8 x 16.9 x 8.9 inch
Notes Replica of Orion 7221 model for Orion 75th anniversary, 1913-1988. FM1, FM2: OIRT, CCIR.
Net weight (2.2 lb = 1 kg) 4 kg / 8 lb 13 oz (8.811 lb)
Price in first year of sale 11'000.00 HUF

Model page created by Sandor Selyem-Tóth. See "Data change" for further contributors.
