For model Inconnu - Unknown 1, Orthodyne Radio; J. Bonhomme; Liège, Bruxelles

Country:  Belgium
Manufacturer / Brand:  Orthodyne Radio; J. Bonhomme; Liège, Bruxelles
Year: 1939 ? Category: Broadcast Receiver - or past WW2 Tuner
Valves / Tubes 6: 6A7 6D6 75 42 6E5 80
Main principle Superheterodyne (common)
Wave bands Broadcast, Long Wave and Short Wave.
Details
Power type and voltage Alternating Current supply (AC) / 110-240 Volt
Loudspeaker Electro Magnetic Dynamic LS (moving-coil with field excitation coil)
Power out
from Radiomuseum.org Model: Inconnu - Unknown 1 - Orthodyne Radio; J. Bonhomme;
Material Wooden case
Shape Tablemodel, low profile (big size).
Dimensions (WHD) 610 x 310 x 280 mm / 24 x 12.2 x 11 inch
Notes

3 wavebands from 16 to 2000 m. Tone control.

Cabinet similar to 385 (5 tubes) and 386 (6 tubes), but slight differences in the speaker grille decoration.

Model page created by David Roussel. See "Data change" for further contributors.
