Adjutant L122W

Adjutant L122W; Owin; Hannover (ID = 1779821) Radio

Adjutant L122W; Owin; Hannover (ID = 25685) Radio

Adjutant L122W; Owin; Hannover (ID = 25686) Radio

Adjutant L122W; Owin; Hannover (ID = 5019) Radio

Adjutant L122W; Owin; Hannover (ID = 1778856) Radio

Adjutant L122W; Owin; Hannover (ID = 1778857) Radio

Adjutant L122W; Owin; Hannover (ID = 1779907) Radio

Adjutant L122W; Owin; Hannover (ID = 1779908) Radio
Adjutant L122W; Owin; Hannover (ID = 256714) Radio Adjutant L122W; Owin; Hannover (ID = 256715) Radio
Adjutant L122W; Owin; Hannover (ID = 256716) Radio Adjutant L122W; Owin; Hannover (ID = 1087950) Radio
Adjutant L122W; Owin; Hannover (ID = 1778855) Radio
Use red slider bar for more.
Adjutant L122W; Owin; Hannover (ID = 256714) Radio
Owin; Hannover: Adjutant L122W [Radio] ID = 256714 498x436
Select picture or schematic to display from thumbnails on the right and click for download.
For model Adjutant L122W, Owin; Hannover

Country:  Germany
Manufacturer / Brand:  Owin; Hannover
Year: 1935/1936 Category: Broadcast Receiver - or past WW2 Tuner
Valves / Tubes 4: AF3 AF7 AL1 AZ1
Main principle TRF with regeneration; 1 Special; 1 AF stage(s)
Tuned circuits 2 AM circuit(s)
Wave bands Broadcast (MW) and Long Wave.
Details
Power type and voltage Alternating Current supply (AC) / 110; 127; 220; 240 Volt
Loudspeaker Electro Magnetic Dynamic LS (moving-coil with field excitation coil)
Power out
from Radiomuseum.org Model: Adjutant L122W - Owin; Hannover
Material Bakelite case
Shape Tablemodel, low profile (big size).
Dimensions (WHD) 435 x 340 x 325 mm / 17.1 x 13.4 x 12.8 inch
Notes Getrennte Abstimmdrehkos der 2 Kreise 1 x vorn und 1 x an der Seite machten das Finden und die Abstimmung bei schwächeren Sendern sehr problematisch. Dieses Gerät war einer jener Fehlschläge von OWIN, die das jähe Ende 1936 einleiteten.
Price in first year of sale 215.00 RM
Source of data Katalog Radio-Zentrale Alex v. Prohaska 1935/1936 / Radiokatalog Band 1, Ernst Erb
Circuit diagram reference Lange+Schenk+FS-Röhrenbestückung


All listed radios etc. from Owin; Hannover
Here you find 220 models, 176 with images and 78 with schematics for wireless sets etc. In French: TSF for Télégraphie sans fil.


Collection of a member from D
