4 Band Solid State Radio 9L-786LD
Use red slider bar for more.
Pars Electric: 4 Band Solid State Radio 9L-786LD [Radio] ID = 1600424 933x650
Select picture or schematic to display from thumbnails on the right and click for download.
|
|
||||
| Year: 1972 ?? | Category: Broadcast Receiver - or past WW2 Tuner | ||||
| Semiconductors (the count is only for transistors) | 9: 2SC784 2SC381 2SA49 2SA53 2SB54 2SB54 2SB56 2SB365 2SB365 |
|---|
| Main principle | Superheterodyne (common) |
|---|---|
| Wave bands | Broadcast, Long Wave and 2 x Short Wave. |
| Details | |
| Power type and voltage | Line / Batteries (any type) / AC: 220 / D: 4 x 1.5 Volt |
| Loudspeaker | Permanent Magnet Dynamic (PDyn) Loudspeaker (moving coil) / Ø 10 cm = 3.9 inch |
| Power out | 1.2 W (max.) |
| from Radiomuseum.org | Model: 4 Band Solid State Radio 9L-786LD - Pars Electric Manufacturing Co |
| Material | Leather / canvas / plastic - over other material |
| Shape | Portable set > 8 inch (also usable without mains) |
| Dimensions (WHD) | 318 x 160 x 100 mm / 12.5 x 6.3 x 3.9 inch |
| Notes |
LW: 150 - 400 kHz Similar to Toshiba/Pars 9L-780LD. |
