For model 209U -02, Philips; Eindhoven (tubes international!); Miniwatt:
My own colletion.

Country:  Netherlands
Manufacturer / Brand:  Philips; Eindhoven (tubes international!); Miniwatt
Year: 1945/1946 Category: Broadcast Receiver - or past WW2 Tuner
Valves / Tubes 4: UCH21 UCH21 UBL21 UY1N
Main principle Superheterodyne (common); ZF/IF 452 kHz
Tuned circuits 6 AM circuit(s)
Wave bands Broadcast, Long Wave and Short Wave.
Details
Power type and voltage AC/DC-set / 125/220 Volt
Loudspeaker Permanent Magnet Dynamic (PDyn) Loudspeaker (moving coil) / Ø 5 inch = 12.7 cm
Power out
from Radiomuseum.org Model: 209U -02 - Philips; Eindhoven tubes
Material Bakelite case
Shape Tablemodel, Mantel/Midget/Compact up to 14" width, but not a Portable (See power data. Sometimes with handle but for mains only).
Dimensions (WHD) 285 x 185 x 155 mm / 11.2 x 7.3 x 6.1 inch
Notes

Nachdem Widerstand R37 kurzgeschlossen ist, kann das Modell mit 110 / 200 V (AC/DC) gespeist werden.

Siehe die Übersicht mit allen 209U-Modellen am Ende dieser Modellseite unter "Dokumenten zu diesem Modell".

Net weight (2.2 lb = 1 kg) 3.3 kg / 7 lb 4.3 oz (7.269 lb)
Price in first year of sale 143.00 Hfl
Mentioned in Technisch- Commercieel - Radio Vademecum Staleman
Literature/Schematics (1) -- Original-techn. papers. (Philips Apparatenblad)
Documents regarding this model
  Übersicht Philips 209U-Modelle 48 KB

Model page created by Iven Müller. See "Data change" for further contributors.
