• Country
• Germany

• Manufacturer / Brand
• Philips Radios - Deutschland

• Year
• 1972

• Category
• Sound/Video Recorder and/or Player

• Radiomuseum.org ID
• 131767

• • Brand: Deutsche Philips-Ges.

Click on the schematic thumbnail to request the schematic as a free document.

• Wave bands
• - without

• Details
• Changer (Record changer)

• Power type and voltage
• Alternating Current supply (AC) / 110; 127; 220; 240 Volt

• Loudspeaker
• - For headphones or amp.

• Material
• Metal case

• from Radiomuseum.org
• Model: 22GC060 /00L /00S /04L /04S /22L /55S /60L - Philips Radios - Deutschland

• Shape
• Chassis only or for «building in»

• Dimensions (WHD)
• 360 x 190 x 290 mm / 14.2 x 7.5 x 11.4 inch

• Notes

• 4-speed record changer chassis for a stack of 6 records.

  Two principal versions:

  • /..S with fixed stylus pressure 5.5 gr, suitable for GP200 and GP300
  • /..L with adjustable pressure 2 - 5 gr, additionally suitable for GP233 and GP410

  Additional cartridges (for L versions) are GP204 and GP205.
  GP380 can be used in conjunction with Preamplifier 22GH905.

  Version /60L is for 60 Hz mains.
  Versions /22 and /55 have unknown differences.

• Net weight (2.2 lb = 1 kg)
• 2.8 kg / 6 lb 2.7 oz (6.167 lb)

• Literature/Schematics (1)
• -- Original-techn. papers.

• Author
• Model page created by Hans-Werner Ellerbrock. See "Data change" for further contributors.
