24TX300A /06

• Country
• Netherlands

• Manufacturer / Brand
• Philips; Eindhoven (tubes international!); Miniwatt

• Year
• 1965 ??

• Category
• Television Receiver (TV) or Monitor

• Radiomuseum.org ID
• 204964

• Picture
• Schematics

Previous Next

Previous Next

Click on the schematic thumbnail to request the schematic as a free document.

• Number of Tubes
• 24

• Valves / Tubes
• EF184 EF184 PCL82 PL84 PCC88 PCF80 EF183 EF183 EF184 PCF80 PCL84 ECC82 PCF80 PCF80 PL36 PY81 DY87 ECC82 ECH83 PCF80 PF86 PCL82 PCF80 AW61-88

• Main principle
• Superheterodyne (common); 2 AF stage(s)

• Wave bands
• VHF incl. FM and/or UHF (see notes for details)

• Power type and voltage
• Alternating Current supply (AC) / 110; 127; 220 Volt

• Loudspeaker
• Permanent Magnet Dynamic (PDyn) Loudspeaker (moving coil) / Ø 8 inch = 20.3 cm

• Material
• Wooden case

• from Radiomuseum.org
• Model: 24TX300A /06 - Philips; Eindhoven tubes

• Shape
• Tablemodel, low profile (big size).

• Dimensions (WHD)
• 620 x 500 x 450 mm / 24.4 x 19.7 x 17.7 inch

• Notes
• • Transformerless audio output stage.
  • 4 standard receiver:
  • Type of loudspeaker: 1 x AD3800AM.
  • VHF channels: (tuner A3 300 48): E2-E11, F6, F8a.
  • No UHF.
  • Remote control unit AT6320-03.
  • Contains semiconductor diodes: 2 x OA210, 6 x OA81, 1 x OA70, 1 x OA202, 3 x BA100.

• Source of data
• -- Original-techn. papers.

• Literature/Schematics (1)
• Service Manual

• Author
• Model page created by Dirk Taekels. See "Data change" for further contributors.
