Octode super 529AU

Octode super 529AU; Philips; Eindhoven (ID = 39575) Radio

Octode super 529AU; Philips; Eindhoven (ID = 39576) Radio

Octode super 529AU; Philips; Eindhoven (ID = 39577) Radio

Octode super 529AU; Philips; Eindhoven (ID = 1914188) Radio

Octode super 529AU; Philips; Eindhoven (ID = 1914189) Radio

Octode super 529AU; Philips; Eindhoven (ID = 1914190) Radio

Octode super 529AU; Philips; Eindhoven (ID = 1914191) Radio

Octode super 529AU; Philips; Eindhoven (ID = 1914192) Radio

Octode super 529AU; Philips; Eindhoven (ID = 1914193) Radio

Octode super 529AU; Philips; Eindhoven (ID = 1914194) Radio
Octode super 529AU; Philips; Eindhoven (ID = 349745) Radio Octode super 529AU; Philips; Eindhoven (ID = 349747) Radio
Octode super 529AU; Philips; Eindhoven (ID = 349746) Radio Octode super 529AU; Philips; Eindhoven (ID = 31376) Radio
Use red slider bar for more.
Octode super 529AU; Philips; Eindhoven (ID = 349745) Radio
Philips; Eindhoven: Octode super 529AU [Radio] ID = 349745 424x505
Select picture or schematic to display from thumbnails on the right and click for download.
For model Octode super 529AU, Philips; Eindhoven (tubes international!); Miniwatt

Country:  Netherlands
Manufacturer / Brand:  Philips; Eindhoven (tubes international!); Miniwatt
Year: 1935/1936 ? Category: Broadcast Receiver - or past WW2 Tuner
Valves / Tubes 4: CK1 CF1 CL2 CY1 C1
Main principle Superhet, IF regeneration; ZF/IF 475 kHz; 2 AF stage(s)
Tuned circuits 4 AM circuit(s)
Wave bands Broadcast (MW) and Long Wave.
Details
Power type and voltage AC/DC-set / 110-250 / AC: 125 Volt
Loudspeaker Permanent Magnet Dynamic (PDyn) Loudspeaker (moving coil) / Ø 17 cm = 6.7 inch
Power out
from Radiomuseum.org Model: Octode super 529AU - Philips; Eindhoven tubes
Material Wooden case
Shape Tablemodel, high profile (upright - NOT Cathedral nor decorative).
Notes
2 Band reception:
  • LW: 760 - 1900 m.
  • BC: 199 - 552 m.
Tuning scale light bulb type: 8070 (10V, 200mA).
Loudspeaker Philips type 4281. Connectors for second loudspeaker and for pick-up.

Model 529AU has a built-in autotransformer so that it can perform on 125V AC as well as on 220V AC or DC, a performance which is not possible with model 529HU on 125V AC. It is however still possible to function as a AC/DC device by bridging point 3 to 4 on the transformers board.

Attention: Chassis connected to the mains !
Literature/Schematics (1) -- Original-techn. papers.

Model page created by Iven Müller. See "Data change" for further contributors.
